Basic Info.
Transport Package
Carton
Specification
9A~400A
Trademark
korlen
Origin
Wenzhou; Zhejiang; China
HS Code
8536900000
Production Capacity
5000PCS/Day
Product Description
AC Contactor with Cheap Price
The series KNC8 AC contactor is suitable for 50/60Hz, rated insulation voltage is 690-1000V, Rated current is 9A-400A at rated operational voltage 380V under the utilization category AC-3. It mainly used for making or breaking circuit at a long distance, suitable for controlling starting\stopping\reversing of AC motor. According with IEC60947 VED0660 GB14048 standards.
1. Good safety, induction parts are inside.
2. Small volume, light weight, material of air chute not easily to break and good arc capability.
3. Air chamber is sealing type, distance of arcover is small, can reduce the measurement Of electric box body.
4. Unique system frame of main contact group, contact abrasion reduce, increase the electro-life.
5. Electromagnet works reliably, abrasion is more less, low noise, having high mechanical Intensity.
6. Frequency operation and controlling capacity are all very high.
7. It's convenient for connection, fastness, high touch reliability, strong vibration resistance, Good safety precaution.
Company Company Introduction
Wenzhou Korlen Electric Appliances Co., Ltd, It is a joint venture. My company is a manufacturer including design, development, produce and sale, professional producing MCB, MCCB, RCCB and AC contactor etc. Product enterprises. The company owns import and export power of self-run, expanding Europe and America, Middle East, Southeast Asia etc. Market, set a good Public praise.
The company have more than 1500 workers, including senior engineer among them, engineer at inside of more than 100 technician. And then set up to cover area more than 50 acres, construct area is more than 38000 square meters of the modern industrial zone, providing with the forerunner's standard laboratory and various examination equipments.
Under Korlen people to make great effort unremittingly, designed and developed by oneself, develop and produce the series of MCB, RCCB filled up local blank, attain inter-national advanced level, and acquire more than 20 national patents. The company acquires "30 strong eminent enterprises, top ten of export income, yueqing star class enterprise, attach importance to contract and keeps promise" title of honor for many times past years. Company still the initiative pass ISO 9001 management system verification and 14001 environments management system verification. Our product passed quality verification of domestic and international authority organization like the CB\ SEMKO\ NF\ SIRIM\ SNI\ CE \PCT\ TSE, In the meantime high breaking capacity breaker of our company in this city is the unique product which got " Yueqing famous brand product" by Yueqing people government.
Korlen Electric Appliances is willing to make friends with social public, the world outside businessman join hands together for prosperous society and development to build a brighter future.
Certificates
Factory Lines
Exhibition
The series KNC8 AC contactor is suitable for 50/60Hz, rated insulation voltage is 690-1000V, Rated current is 9A-400A at rated operational voltage 380V under the utilization category AC-3. It mainly used for making or breaking circuit at a long distance, suitable for controlling starting\stopping\reversing of AC motor. According with IEC60947 VED0660 GB14048 standards.
1. Good safety, induction parts are inside.
2. Small volume, light weight, material of air chute not easily to break and good arc capability.
3. Air chamber is sealing type, distance of arcover is small, can reduce the measurement Of electric box body.
4. Unique system frame of main contact group, contact abrasion reduce, increase the electro-life.
5. Electromagnet works reliably, abrasion is more less, low noise, having high mechanical Intensity.
6. Frequency operation and controlling capacity are all very high.
7. It's convenient for connection, fastness, high touch reliability, strong vibration resistance, Good safety precaution.
| Type | KNC8-40 | KNC8-41 | KNC8-44 | KNC8-46 | KNC8-47 | KNC8-48 | KNC8-49 | KNC8-50 | KNC8-52 | KNC8-54 | KNC8-56 | ||
| Rated insulation voltage(V) | 690 | 690 | 690 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | ||
| Rated operational current(380V | AC-3 | 9 | 12 | 32 | 45 | 63 | 75 | 85 | 110 | 170 | 250 | 400 | |
| AC-4 | 3.3 | 3.3 | 15.5 | 24 | 28 | 34 | 42 | 54 | 75 | 110 | 150 | ||
| Rated outputs of three-phase motors at 50Hz | AC-3 AC-4 | 230/220V | 2.4 | 2.4 | 8.5 | 15 | 18.5 | 22 | 26 | 37 | 55 | 78 | 125 |
| 400/380V | 4 | 4 | 15 | 22 | 30 | 37 | 45 | 55 | 90 | 132 | 200 | ||
| 500V | 5.5 | 5.5 | 21 | 30 | 41 | 50 | 59 | 76 | 118 | 178 | 284 | ||
| 690/660V | 5.5 | 5.5 | 23 | 39 | 55 | 67 | 67 | 100 | 159 | 235 | 375 | ||
| 1000V | - | - | - | - | - | 39 | 39 | 65 | 90 | 132 | 250 | ||
| 400/380V | 1.48/1.4 | 1.48/1.4 | 7.5 | 12.6/12 | 14.7/14 | 17.9/17 | 22/21 | 28.4/27 | 40/38 | 61/58 | 85/81 | ||
| 690/660 | 2.54/2.4 | 2.54/2.4 | 13 | 21.8/20.8 | 25.4/24.3 | 30.9/29.5 | 38/36 | 49/46.9 | 69/66 | 105/100 | 147/140 | ||
| Mechanical endurance(×10 6 ) (0.8-1.1)Us | |||||||||||||
| Electrical endurance(×10 6 ) | AC-3 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | |
| AC-4 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | ||
| Switching frequency | AC-3 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | |
| AC-4 | 1000 | 1000 | 750 | 1200 | 1000 | 1000 | 850 | 100 | 700 | 700 | 500 | ||
| Coil voltage tolerance | 250 | 250 | 250 | 400 | 300 | 300 | 250 | 300 | 200 | 200 | 150 | ||
| Power consumption of coil(50Hz | Closed(VA) | 10 | 10 | 12.1 | 17 | 17 | 32 | 32 | 39 | 58 | 84 | 115 | |
| p.f. | 0.29 | 0.29 | 0.28 | 0.29 | 0.29 | 0.23 | 0.23 | 0.24 | 0.26 | 0.24 | 0.33 | ||
| Colsing(VA) | 6.8 | 6.8 | 101 | 183 | 183 | 330 | 330 | 550 | 910 | 1430 | 2450 | ||
| p.f. | 0.82 | 0.82 | 0.83 | 0.6 | 0.6 | 0.5 | 0.5 | 0.45 | 0.38 | 0.34 | 0.21 | ||
| Conventional thermal current | 20 | 20 | 55 | 80 | 90 | 100 | 100 | 140 | 210 | 300 | 400 | ||
| Conventional thermal current of auxiliary contacts | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | ||
| Rated operational current of auxiliary contacts | AC-15 380/220V | 6/10 | 6/10 | 4/6 | 4/6 | 4/6 | 4/6 | 4/6 | 4/6 | 4/6 | 4/6 | 4/6 | |
