Basic Info.
Model NO.
AG-VDF-2B-100A
Poles Number
1
Type
Circuit Breaker
Function
RCCB
Certification
CE, CB, CCC
Mode
Electro-Magnetic Type
Rated Voltage
AC 230(240)/400(415)
Electro-Mechanical Endurance
4000 Cycle
Protection
IP20
Terminal Connection Height: 19mm
19mm
Connection Terminal
Screw Terminal
Supply Ability
10000 Pole/Poles Per Month
Transport Package
Carton
Specification
36*78*81mm
Trademark
AEGEN
Origin
China
HS Code
8538900000
Production Capacity
10000 Pole/Poles Per Month
Product Description
Residual current circuit breakers (RCCBs)
This device is essentially a attached to it. So basically it will only break the circuit when there is a leakage current flowing to earth. The tripping time is such as to minimise the risk to human life.
RCCBs usually have a fault making and . This means that they can handle a fault of 1 kA on their own if it is a fault to earth.
Type B residual current device disconnects the power if the earth leakage current is detected as dangerous. If the earth leakage current is equal to or less than 10mA, then the Type B residual current devices would not trip because this current amount is not dangerous. The electric car will continue to get charging without any interruption. The Type B residual current devices will immediately trip the circuit and disconnect the power supply for higher currents. Like this, Type B residual current devices will protect the circuits from danger.
This device is essentially a attached to it. So basically it will only break the circuit when there is a leakage current flowing to earth. The tripping time is such as to minimise the risk to human life.
RCCBs usually have a fault making and . This means that they can handle a fault of 1 kA on their own if it is a fault to earth.
Type B residual current device disconnects the power if the earth leakage current is detected as dangerous. If the earth leakage current is equal to or less than 10mA, then the Type B residual current devices would not trip because this current amount is not dangerous. The electric car will continue to get charging without any interruption. The Type B residual current devices will immediately trip the circuit and disconnect the power supply for higher currents. Like this, Type B residual current devices will protect the circuits from danger.
| Technical Data | |
| Model: | AG-VDF-2B-63A |
| Pole No.: | 1P+N, 3P+N |
| Rated current(A): | 16A,25A, 32A, 40A, 63A,80A,100A |
| Rated working voltage(I n): | 30, 100, 300, 500mA |
| Rated voltage(V): | AC 230(240)/400(415) |
| Rated frequency(Hz): | 50/60 |
| Rated making and breaking capacity: | 500(In=25A,32,40A), 630(In=63A) |
| Rated conditional short-circuit current Inc: | 10000A |
| Rated conditional residual short-circuit Current I c: | 10000A |
| Rated residual non operating current I no: | 0.5I n |
| Residual operating current range: | 0.5I n~I n |
| Operating time: | ≤0.3s |
| Type: | A and AC type |
| Rated short-circuit breaking capacity: | 10000A |
| Mechanical life: | 2000 times |
| Degree of protection: | IP20 |
| Products name: | Type B RCD | Type B RCCB | Detection residential RCCB |
